Flexible DC Solar Cable (KUKA Cables)
These Flexible DC Solar Cables are made for solar power systems that need to be very reliable, safe, and last a long time. These cables are great for solar farm operators, EPC contractors, and renewable energy projects since they keep the electrical efficiency high even in bad weather.
Product Description
The cable meets IEC62930 and TUV requirements and has high-quality tinned copper multi-strand conductors and XLPO insulation that can withstand UV rays and heat. It also has electron-beam cross-linking. It is built to last, with a uniform thickness and very little irregularity. It should last for 30 years.
It can handle conductor temperatures up to +120°C (20,000 hours) and works securely in temperatures between -40°C and +90°C. It is rated for DC 1500V and AC 1000V. The cable also satisfies EN 60332-1-1 flame resistance standards and has ROHS, CE, and TUV certifications. This means it is safe and works well for tough solar applications.
Key Features:
- Voltage rating: DC 1500V / AC 1000V
- Max conductor temperature: +120°C (20,000 hours)
- Flame resistance: EN 60332-1-1
- Temperature range: -40°C to +90°C
- High-grade tinned copper multi-strand conductor
- UV- and heat-resistant XLPO insulation, electron-beam cross-linked
- Certified: IEC62930, TUV, ROHS, CE
- Available sizes: 1×4 mm², 1×6 mm²
